Visualize CLOSURE data in an ECDF plot

Source: R/plot-ecdf-basic.R
closure_plot_ecdf.Rd

Call closure_plot_ecdf() to visualize CLOSURE results using the data's empirical cumulative distribution function (ECDF). This can be useful to display any variation between CLOSURE samples.

See closure_plot_bar() for more intuitive visuals.

Usage

closure_plot_ecdf(
  data,
  samples = c("mean_min_max", "mean", "all"),
  pad = c("extend", "match", "stop"),
  legend_title = NULL,
  line_color_single = "#5D3FD3",
  line_color_multiple = c("royalblue4", "deeppink", "darkcyan"),
  text_size = 12,
  reference_line_alpha = 0.6,
  mark_decimal = "."
)

Arguments

data

List returned by closure_generate() or closure_read().

samples

String (length 1). How to map the samples to ECDF lines?

  • "mean_min_max", the default, draws three lines: overall mean across all samples, mean of the samples with the minimum horns index, and mean of the samples with the maximum horns index.

  • "mean" draws a single line for the overall mean.

  • "all" draws a separate line for each sample, colored by its horns index value. Note: This is invalid if data$results does not include the sample and horns columns. If many samples were found, it can be very slow or even crash your R session.

pad

String (length 1). How far should the ECDF line(s) stretch?

  • "extend", the default, draws the lines to both ends of the y-axis vertically and slightly beyond that horizontally, as ggplot2::stat_ecdf() does by default.

  • "match" draws them vertically as above, but not horizontally. Note: This is currently invalid in combination with samples = "all".

  • "stop" does not draw the lines beyond the data points at all.

legend_title

String (length 1). Defaults for the legend title depend on samples:

  • With samples = "mean_min_max", the legend title is absent by default because it can make the legend extend beyond the plot itself. If you do choose a title, consider legend_title = "Subset of samples".

  • With samples = "mean", there is no legend, and hence no title.

  • With samples = "all", the title says "Horns index" unless you provide a different one.

To remove the legend or change its position, use legend.position in ggplot2::theme().

line_color_single

String (length 1). If samples is "mean", this is the color of the single ECDF line. Default is "#5D3FD3", a purple color.

line_color_multiple

String (length 3). If samples is "mean_min_max", these are the colors of the three ECDF lines. Default is "royalblue4" for the overall mean, "deeppink" for the minimum horns index, and "darkcyan" for the maximum horns index; in this order.

If samples is "all", the colors for min and max horns index values are used for the low and high ends of the gradient.

text_size

Numeric (length 1). Base font size in pt. Default is 12.

reference_line_alpha

Numeric (length 1). Opacity of the diagonal reference line. Default is 0.6.

mark_decimal

String (length 1). Decimal delimiter in the labels. Default is "." (e.g., "0.15").

Value

A ggplot object.

Details

This function was inspired by rsprite2::plot_distributions() with its option plot_type = "ecdf". However, plot_distributions() invariably shows one line per (randomly drawn) possible dataset, and it does not support the horns index or other measures of dispersion. Some further differences exist.

Examples

# Create CLOSURE data first:
data <- closure_generate(
  mean = "3.5",
  sd = "2",
  n = 52,
  scale_min = 1,
  scale_max = 5
)
#>
#> ✔ All CLOSURE results found

# Visualize:
closure_plot_ecdf(data)
